FIS121NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FIS121NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FIS121NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FIS121NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | CURR SENSE XFMR 1:200 15A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 55 pcs | 110 pcs |
|---|---|---|---|---|---|
| $0.883 | $0.706 | $0.574 | $0.559 | $0.544 | |
| 275 pcs | 550 pcs | 1045 pcs | 5005 pcs | ||
| $0.53 | $0.525 | $0.465 | $0.427 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | FIS121NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:200 15A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 84313 pcs | Data sheet | FIS Series |
| Category | Transformers | Weight | - |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | 1:200 |
| Termination Style | PC Pin | Size / Dimension | 0.677" L x 0.375" W (17.20mm x 9.53mm) |
| Series | FIS | Ratings | - |
| Packaging | Bulk | Other Names | 553-1835-5 FIS121NL-ND |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 94.5mH | Height - Seated (Max) | 0.803" (20.40mm) |
| Frequency Range | 200kHz Max | Energy Time (E.T.) | 700V µS |
| Detailed Description | 1:200 Current Sense Transformer 200kHz Max 4.5 Ohm Max 94.5mH Through Hole | DC Resistance (DCR) | 4.5 Ohm Max |
| Current Ratio | - |
