2SD315AI UL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SD315AI UL with confidence from Components-World.HK, 1 Year Warranty
Dowload 2SD315AI UL Details in PDFSee Product Specifications for product details.
Buy 2SD315AI UL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2SD315AI UL |
|---|---|
| Manufacturer | Power Integrations |
| Description | IC DUAL GATE DRIVER 18A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 40 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $40.138 | $34.115 | $32.109 | $29.283 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2SD315AI UL | Manufacturer | Power Integrations |
|---|---|---|---|
| Description | IC DUAL GATE DRIVER 18A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1121 pcs | Data sheet | 2SD315AI ULSCALE-1 Manual |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 15V |
| Supplier Device Package | Module | Series | SCALE™-1 |
| Rise / Fall Time (Typ) | - | Packaging | Tray |
| Package / Case | Module | Other Names | 1810-1001 |
| Operating Temperature | -40°C ~ 85°C (TA) | Number of Drivers | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Logic Voltage - VIL, VIH | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | - | Gate Type | IGBT, N-Channel, P-Channel MOSFET |
| Driven Configuration | Half-Bridge | Detailed Description | Half-Bridge Gate Driver IC Module |
| Current - Peak Output (Source, Sink) | 18A, 18A | Channel Type | - |
