APTM10TAM09FPG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy APTM10TAM09FPG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy APTM10TAM09FPG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | APTM10TAM09FPG |
|---|---|
| Manufacturer | Microsemi |
| Description | MOSFET 6N-CH 100V 139A SP6-P |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | ||||
|---|---|---|---|---|---|
| $48.849 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | APTM10TAM09FPG | Manufacturer | Microsemi |
|---|---|---|---|
| Description | MOSFET 6N-CH 100V 139A SP6-P | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 786 pcs | Data sheet | APTM10TAM09FPG |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 2.5mA |
| Supplier Device Package | SP6-P | Series | - |
| Rds On (Max) @ Id, Vgs | 10 mOhm @ 69.5A, 10V | Power - Max | 390W |
| Packaging | Bulk | Package / Case | SP6 |
| Operating Temperature | -40°C ~ 150°C (TJ) | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 32 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 9875pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 350nC @ 10V | FET Type | 6 N-Channel (3-Phase Bridge) |
| FET Feature | Standard | Drain to Source Voltage (Vdss) | 100V |
| Detailed Description | Mosfet Array 6 N-Channel (3-Phase Bridge) 100V 139A 390W Chassis Mount SP6-P | Current - Continuous Drain (Id) @ 25°C | 139A |
