RGTVX6TS65GC11
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RGTVX6TS65GC11 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RGTVX6TS65GC11 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RGTVX6TS65GC11 |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | 650V 80A FIELD STOP TRENCH IGBT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $2.581 | $2.302 | $2.072 | $1.888 | ||
| 250 pcs | 500 pcs | 1000 pcs | |||
| $1.704 | $1.529 | $1.289 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | RGTVX6TS65GC11 | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | 650V 80A FIELD STOP TRENCH IGBT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 29508 pcs | Data sheet | RGTVX6TS65 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 650V |
| Vce(on) (Max) @ Vge, Ic | 1.9V @ 15V, 80A | Test Condition | 400V, 80A, 10 Ohm, 15V |
| Td (on/off) @ 25°C | 45ns/201ns | Switching Energy | 2.65mJ (on), 1.8mJ (off) |
| Supplier Device Package | TO-247N | Series | - |
| Power - Max | 404W | Package / Case | TO-247-3 |
| Operating Temperature | -40°C ~ 175°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | Standard |
| IGBT Type | Trench Field Stop | Gate Charge | 171nC |
| Detailed Description | IGBT Trench Field Stop 650V 144A 404W Through Hole TO-247N | Current - Collector Pulsed (Icm) | 320A |
| Current - Collector (Ic) (Max) | 144A |
