Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > BD9611MUV-EVK-001

BD9611MUV-EVK-001

BD9611MUV-EVK-001

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BD9611MUV-EVK-001 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	BD9611MUV-EVK-001
Manufacturer	LAPIS Semiconductor
Description	EVAL BOARD BD9611 MUV
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1096 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$31.023

Product parameter
Data sheet

Product parameter

Part Number	BD9611MUV-EVK-001	Manufacturer	LAPIS Semiconductor
Description	EVAL BOARD BD9611 MUV	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1096 pcs	Data sheet	BD9611MUV-EVK-001 Guide BD9611MUV
Category	Development Boards, Kits, Programmers	Voltage - Output	12V
Voltage - Input	15 V ~ 36 V	Utilized IC / Part	BD9611
Supplied Contents	Board(s)	Series	-
Regulator Topology	Buck	Outputs and Type	1, Non-Isolated
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	10 Weeks
Main Purpose	DC/DC, Step Down	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Frequency - Switching	250kHz	Detailed Description	BD9611 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Current - Output	10A	Board Type	Fully Populated
