09120080428
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09120080428 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09120080428 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09120080428 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN HOOD TOP ENTRY |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.30 | $3.909 | $3.812 | $3.518 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.323 | $3.03 | $2.834 | $2.60 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09120080428 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN HOOD TOP ENTRY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11856 pcs | Data sheet | 09120080428 Drawing |
| Category | Connectors, Interconnects | Thread Size | - |
| Style | Top Entry | Size / Dimension | 1.886" L x 1.130" W x 2.126" H (47.90mm x 28.70mm x 54.00mm) |
| Size | - | Series | Han-Compact® |
| Packaging | Bulk | Other Names | 09120080428-ND 1195-7476 |
| Operating Temperature | -40°C ~ 125°C | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 3 Weeks | Lock Location | Locking Clip (1) on Base Bottom |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP65/67 - Dust Tight, Water Resistant, Waterproof |
| Housing Material | Thermoplastic | Housing Finish | - |
| Housing Color | Black | Features | - |
| Connector Type | Hood |
