IRFD9220
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IRFD9220 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy IRFD9220 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | IRFD9220 |
|---|---|
| Manufacturer | Electro-Films (EFI) / Vishay |
| Description | MOSFET P-CH 200V 0.56A 4-DIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | IRFD9220 | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | MOSFET P-CH 200V 0.56A 4-DIP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5003 pcs | Data sheet | IRFD9220 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 4-DIP, Hexdip, HVMDIP | Series | - |
| Rds On (Max) @ Id, Vgs | 1.5 Ohm @ 340mA, 10V | Power Dissipation (Max) | 1W (Ta) |
| Packaging | Tube | Package / Case | 4-DIP (0.300", 7.62mm) |
| Other Names | *IRFD9220 | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Input Capacitance (Ciss) (Max) @ Vds | 340pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 15nC @ 10V | FET Type | P-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Drain to Source Voltage (Vdss) | 200V | Detailed Description | P-Channel 200V 560mA (Ta) 1W (Ta) Through Hole 4-DIP, Hexdip, HVMDIP |
| Current - Continuous Drain (Id) @ 25°C | 560mA (Ta) |
