Home > Products > Kits > Transformer Kits > B82801X0003

B82801X0003

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B82801X0003 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B82801X0003
Manufacturer	EPCOS
Description	SMT CURRENT SENSE TRANSFORMERS K
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2916 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
Reference Price (In US Dollars)	$16.002	$15.468	$14.401	$13.335

Product parameter
Data sheet

Product parameter

Part Number	B82801X0003	Manufacturer	EPCOS
Description	SMT CURRENT SENSE TRANSFORMERS K	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2916 pcs	Data sheet	B82801X3 Datasheet B82801C Series
Category	Kits	Series	B82801C
Quantity	8 Pieces (4 Values - 2 Each)	Packaging	Plastic Box with Bin Guide
Other Names	495-7212 B82801X 3 B82801X 3 B82801X3	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	33 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Kit Type	Current Sense
