Home > Products > Magnetics - Transformer, Inductor Components > Ferrite Cores > B64290L0038X830

B64290L0038X830

B64290L0038X830

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B64290L0038X830 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B64290L0038X830
Manufacturer	EPCOS
Description	FERRITE CORE TOROID 1.76UH N30
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 657681 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.102	$0.082	$0.069	$0.061	$0.054
	$0.047	$0.043	$0.036	$0.034

Product parameter
Data sheet

Product parameter

Part Number	B64290L0038X830	Manufacturer	EPCOS
Description	FERRITE CORE TOROID 1.76UH N30	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	657681 pcs	Data sheet	B64290L0038 Datasheet Ferrites, Accessories General Info
Category	Magnetics - Transformer, Inductor Components	Width	-
Tolerance	±25%	Supplier Device Package	-
Series	B64290	Other Names	495-3848 B64290L 38X830 B64290L 38X830 B64290L38X830
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material	N30
Manufacturer Standard Lead Time	24 Weeks	Length	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Initial Permeability (µi)	4300
Inductance Factor (Al)	1.76µH	Height	4.75mm
Gap	Ungapped	Finish	Epoxy
Effective Magnetic Volume (Ve) mm³	188	Effective Length (le) mm	24.07
Effective Area (Ae) mm²	7.83	Diameter	10.80mm
Core Type	Toroid	Core Factor (ΣI/A) mm1	3.07
