Home > Products > Switches > Snap Action, Limit Switches > E20-50H

E20-50H

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E20-50H with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	E20-50H
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION DPDT 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 12253 pcs
Reference Price (In US Dollars)	1008 pcs
Reference Price (In US Dollars)	$2.538

Product parameter
Data sheet

Product parameter

Part Number	E20-50H	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION DPDT 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	12253 pcs	Data sheet	E19,20, G20 Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.250" (6.3mm)	Switch Function	On-Mom
Series	E	Release Force	-
Pretravel	0.600" (15.24mm)	Packaging	Bulk
Overtravel	0.156" (3.96mm)	Other Names	0E20-50H 0E20-50H0 0E2050H0 CH506 E20-50H-ND E20-50H0 E2050H Q584348
Operating Temperature	-40°C ~ 105°C	Operating Position	0.437" (11.1mm)
Operating Force	285gf	Mounting Type	Chassis Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	-
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	-
Electrical Life	6,000 Cycles	Differential Travel	0.080" (2.0mm)
Current Rating	20A (AC)	Circuit	DPDT
Actuator Type	Lever, Straight
