Home > Products > Switches > Snap Action, Limit Switches > E20-00M

E20-00M

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E20-00M with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	E20-00M
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION DPDT 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 13674 pcs
Reference Price (In US Dollars)	900 pcs
Reference Price (In US Dollars)	$2.706

Product parameter
Data sheet

Product parameter

Part Number	E20-00M	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION DPDT 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	13674 pcs	Data sheet	E19,20, G20 Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.250" (6.3mm)	Switch Function	On-Mom
Series	E	Release Force	-
Pretravel	0.100" (2.5mm)	Packaging	Bulk
Overtravel	0.187" (4.75mm)	Other Names	0E20-00M 0E20-00M0 0E2000M0 0E2000MO CH329 E20-00M0
Operating Temperature	-40°C ~ 105°C	Operating Position	0.776" (19.7mm)
Operating Force	1280gf	Mounting Type	Panel Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	-
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Features	-
Electrical Life	6,000 Cycles	Differential Travel	0.015" (0.38mm)
Current Rating	20A (AC)	Circuit	DPDT
Actuator Type	Overtravel Plunger
