Home > Products > Switches > Snap Action, Limit Switches > E13-01E

E13-01E

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E13-01E with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	E13-01E
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACT SPST-NO 15A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 41647 pcs
Reference Price (In US Dollars)	1000 pcs
Reference Price (In US Dollars)	$0.783

Product parameter
Data sheet

Product parameter

Part Number	E13-01E	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACT SPST-NO 15A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	41647 pcs	Data sheet	E13,14, G13 Series Datasheet
Category	Switches	Voltage Rating - DC	48V
Voltage Rating - AC	125V	Termination Style	Quick Connect - 0.250" (6.3mm)
Switch Function	Off-Mom	Series	E
Release Force	-	Pretravel	0.050" (1.27mm)
Packaging	Bulk	Overtravel	0.100" (2.54mm)
Other Names	0E13-01A 0E13-01E0 0E1301E0 CH500 E13-01A0 E1301E	Operating Temperature	-40°C ~ 105°C
Operating Position	0.285" (7.24mm)	Operating Force	425gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Manufacturer Standard Lead Time	18 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Features	-	Electrical Life	6,000 Cycles
Differential Travel	0.015" (0.38mm)	Current Rating	15A (AC), 2A (DC)
Circuit	SPST-NO	Actuator Type	Round (Pin Plunger)
