Home > Products > Switches > Snap Action, Limit Switches > E13-00H

E13-00H

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E13-00H with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	E13-00H
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION SPDT 15A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 32690 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$1.902	$1.52	$1.444	$1.406
	$1.216	$1.14	$1.083	$1.045

Product parameter
Data sheet

Product parameter

Part Number	E13-00H	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION SPDT 15A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	32690 pcs	Data sheet	E13,14, G13 Series Datasheet
Category	Switches	Voltage Rating - DC	48V
Voltage Rating - AC	125V	Termination Style	Quick Connect - 0.250" (6.3mm)
Switch Function	On-Mom	Series	E
Release Force	-	Pretravel	0.250" (6.35mm)
Packaging	Bulk	Overtravel	0.187" (4.75mm)
Other Names	0E13-00H 0E13-00H0 0E1300H0 0E1300HO CH312 E13-00H0 E1300H	Operating Temperature	-40°C ~ 105°C
Operating Position	0.312" (7.9mm)	Operating Force	100gf
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Manufacturer Standard Lead Time	18 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Features	-	Electrical Life	6,000 Cycles
Differential Travel	0.093" (2.36mm)	Current Rating	15A (AC), 2A (DC)
Circuit	SPDT	Actuator Type	Lever, Straight
