HCP1104-R90-R
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HCP1104-R90-R with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HCP1104-R90-R with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HCP1104-R90-R |
|---|---|
| Manufacturer | Bussmann (Eaton) |
| Description | FIXED IND 900NH 22A 2.5 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HCP1104-R90-R | Manufacturer | Bussmann (Eaton) |
|---|---|---|---|
| Description | FIXED IND 900NH 22A 2.5 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5564 pcs | Data sheet | HCP1104 Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.453" L x 0.394" W (11.50mm x 10.00mm) | Shielding | Unshielded |
| Series | HCP1104 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 513-1375-2 |
| Operating Temperature | -55°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron Powder |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 900nH | Height - Seated (Max) | 0.157" (4.00mm) |
| Frequency - Self Resonant | - | Detailed Description | 900nH Unshielded Wirewound Inductor 22A 2.5 mOhm Max Nonstandard |
| DC Resistance (DCR) | 2.5 mOhm Max | Current Rating | 22A |
| Current - Saturation | 25A |
