HSMF-C113
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HSMF-C113 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HSMF-C113 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HSMF-C113 |
|---|---|
| Manufacturer | Avago Technologies (Broadcom Limited) |
| Description | LED RGB DIFFUSED CHIP SMD R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | ||
|---|---|---|---|---|---|
| $0.147 | $0.143 | $0.138 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HSMF-C113 | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | LED RGB DIFFUSED CHIP SMD R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 173356 pcs | Data sheet | LED Solutions Selection GuideHSMF-C113/115 |
| Category | Optoelectronics | Wavelength - Peak | 637nm Red, 570nm Green, 468nm Blue |
| Wavelength - Dominant | 626nm Red, 572nm Green, 470nm Blue | Voltage - Forward (Vf) (Typ) | 1.9V Red, 2V Green, 3.4V Blue |
| Viewing Angle | 120° Red, 125° Green, 125° Blue | Supplier Device Package | Chip LED |
| Size / Dimension | 2.50mm L x 1.00mm W | Series | - |
| Packaging | Tape & Reel (TR) | Package / Case | 4-SMD, No Lead |
| Other Names | 516-2232-2 HSMF-C113-ND HSMFC113 |
Mounting Type | Surface Mount, Right Angle |
| Moisture Sensitivity Level (MSL) | 2A (4 Weeks) | Millicandela Rating | 80mcd Red, 50mcd Green, 60mcd Blue |
| Manufacturer Standard Lead Time | 5 Weeks | Lens Transparency | Diffused |
| Lens Style/Size | Rectangle with Domed Top, 2.10mm x 1.00mm | Lens Color | White |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height (Max) | 1.00mm |
| Features | - | Detailed Description | Red, Green, Blue (RGB) 626nm Red, 572nm Green, 470nm Blue LED Indication - Discrete 1.9V Red, 2V Green, 3.4V Blue 4-SMD, No Lead |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue | Configuration | Common Anode |
| Color | Red, Green, Blue (RGB) | Base Part Number | HSMF-C11 |
