Home > Products > Switches > Rocker Switches > H8500XBBBR-A-B

H8500XBBBR-A-B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H8500XBBBR-A-B with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	H8500XBBBR-A-B
Manufacturer	Arcolectric (Bulgin)
Description	SWITCH ROCKER SPST 15A 250V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 55118 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$1.10	$1.074	$1.023	$0.972	$0.921
	$0.895	$0.87	$0.767	$0.716

Product parameter
Data sheet

Product parameter

Part Number	H8500XBBBR-A-B	Manufacturer	Arcolectric (Bulgin)
Description	SWITCH ROCKER SPST 15A 250V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	55118 pcs	Data sheet	8500 Series Datasheet Rocker Switch Catalog
Category	Switches	Voltage Rating - AC	250V
Termination Style	Quick Connect - 0.187" (4.7mm)	Switch Function	On-Off
Series	8500	Panel Cutout Dimensions	Rectangular - 19.30mm x 12.90mm
Packaging	Bulk	Other Names	1091-1217 H8500XBAAEB H8500XBBBRAB
Operating Temperature	-	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	-
Manufacturer Standard Lead Time	16 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Features	Antimicrobial, Two-Tone Rocker
Electrical Life	-	Detailed Description	Rocker Switch SPST 15A (AC) 250V Panel Mount, Snap-In
Current Rating	15A (AC)	Color - Actuator/Cap	Black, Red
Circuit	SPST	Actuator Type	Concave (Curved)
Actuator Marking	No Marking
