Home > Products > RF/IF and RFID > RF Directional Coupler > X3C09P2-30S

X3C09P2-30S

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy X3C09P2-30S with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	X3C09P2-30S
Manufacturer	Anaren
Description	RF DIR COUPLER 800MHZ-1GHZ 4SMD
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 54620 pcs
Reference Price (In US Dollars)	2000 pcs
Reference Price (In US Dollars)	$0.706

Product parameter
Data sheet

Product parameter

Part Number	X3C09P2-30S	Manufacturer	Anaren
Description	RF DIR COUPLER 800MHZ-1GHZ 4SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	54620 pcs	Data sheet	X3C09P2-30S
Category	RF/IF and RFID	Supplier Device Package	4-SMD
Series	Xinger III®	Return Loss	24.9dB
Power - Max	225W	Packaging	Tape & Reel (TR)
Package / Case	2520 (6450 Metric)	Other Names	1173-1107-2 X3C09P2-30S REEL 3DB X3C09P2-30SR X3C09P230S
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	9 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Isolation	-
Insertion Loss	0.1dB	Frequency	800MHz ~ 1GHz
Detailed Description	RF Directional Coupler AMPS, CDMA, WCDMA 800MHz ~ 1GHz 30.2dB 225W 2520 (6450 Metric)	Coupling Factor	30.2dB
Coupler Type	Standard	Applications	AMPS, CDMA, WCDMA
