1-5530843-0
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1-5530843-0 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1-5530843-0 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1-5530843-0 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN CARDEDGE FEMALE 86POS 0.100 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.351 | $2.252 | $2.057 | $1.959 | $1.861 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $1.665 | $1.567 | $1.371 | $1.302 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1-5530843-0 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN CARDEDGE FEMALE 86POS 0.100 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 24998 pcs | Data sheet | Card Edge Products Catalog5530843 Drawing |
| Category | Connectors, Interconnects | Termination | Solder |
| Series | Standard Edge II | Read Out | Dual |
| Pitch | 0.100" (2.54mm) | Packaging | Bulk |
| Operating Temperature | -55°C ~ 85°C | Number of Rows | 2 |
| Number of Positions/Bay/Row | - | Number of Positions | 86 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | Polyester, Glass Filled | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Gender | Female |
| Flange Feature | - | Features | - |
| Contact Type | - | Contact Material | Phosphor Bronze |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold |
| Color | Black | Card Type | Multibus I |
| Card Thickness | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) |
