19198-0070
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 19198-0070 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 19198-0070 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 19198-0070 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN SPADE TERM 18-22AWG #6 RED |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.117 | $0.11 | $0.094 | $0.08 | $0.077 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.069 | $0.066 | $0.055 | $0.05 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 19198-0070 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN SPADE TERM 18-22AWG #6 RED | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 444285 pcs | Data sheet | 19198-0070 |
| Category | Connectors, Interconnects | Wire Gauge | 18-22 AWG |
| Width - Outer Edges | 0.316" (8.03mm) | Tongue Inside Opening | 0.146" (3.71mm) |
| Termination | Crimp | Terminal Type | Standard |
| Stud/Tab Size | 6 Stud | Series | Avikrimp |
| Packaging | Bulk | Other Names | 019198-0070 019198-0070-C 0191980070 0191980070-C 191-98-0070-C 19198-0070-C 191980070 191980070-C AA-835-06 WM18363 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 5 Weeks |
| Length - Termination | 0.400" (10.16mm) | Length - Ring Center to Termination | 0.303" (7.70mm) |
| Length - Overall | 0.915" (23.24mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Diameter | 0.140" (3.56mm) | Insulation | Insulated |
| Features | - | Detailed Description | Red 6 Stud Spade Terminal Connector Crimp 18-22 AWG |
| Contact Material | Copper | Contact Finish | Electro-Tin |
| Color | Red |
