19198-0047
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 19198-0047 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 19198-0047 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 19198-0047 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN SPADE TERM 10-12AWG #8 YEL |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.168 | $0.159 | $0.143 | $0.127 | $0.122 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.111 | $0.106 | $0.087 | $0.079 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 19198-0047 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN SPADE TERM 10-12AWG #8 YEL | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 297890 pcs | Data sheet | 19198-0047 |
| Category | Connectors, Interconnects | Wire Gauge | 10-12 AWG |
| Width - Outer Edges | 0.375" (9.53mm) | Tongue Inside Opening | 0.173" (4.39mm) |
| Termination | Crimp | Terminal Type | Standard |
| Stud/Tab Size | 8 Stud | Series | Avikrimp |
| Packaging | Bulk | Other Names | 0191980047 191-98-0047-C 19198-0047-C 191980047 C-841-08 WM18371 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 5 Weeks |
| Length - Termination | 0.560" (14.22mm) | Length - Ring Center to Termination | 0.301" (7.65mm) |
| Length - Overall | 1.118" (28.40mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Diameter | 0.225" (5.72mm) | Insulation | Insulated |
| Features | - | Detailed Description | Yellow 8 Stud Spade Terminal Connector Crimp 10-12 AWG |
| Contact Material | Copper | Contact Finish | Electro-Tin |
| Color | Yellow |
