0836129024
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0836129024 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0836129024 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0836129024 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN MICROD PLUG 15POS VERT SLDR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.506 | $5.005 | $4.88 | $4.505 | ||
| 132 pcs | 264 pcs | 528 pcs | 1056 pcs | ||
| $4.254 | $3.879 | $3.629 | $3.328 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0836129024 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN MICROD PLUG 15POS VERT SLDR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11484 pcs | Data sheet | 0836129024 Drawing |
| Category | Connectors, Interconnects | Wire Gauge | - |
| Voltage Rating | - | Termination | Solder |
| Shell Size, Connector Layout | 0.050 Pitch x 0.043 Row to Row | Shell Material, Finish | Steel, Nickel Plated |
| Series | Commercial Micro-D Series 83612 | Packaging | Tube |
| Other Names | 0836129024-ND 83612-9024 836129024 WM14798 |
Operating Temperature | -40°C ~ 125°C |
| Number of Rows | 2 | Number of Positions | 15 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Housing Material | Liquid Crystal Polymer (LCP) | Flange Feature | Mating Side, Female Screwlock (2-56) |
| Features | Board Lock, Shielded | Detailed Description | 15 Position D-Type, Micro-D Plug, Male Pins Connector |
| Current Rating | 1A | Contact Type | Signal |
| Contact Material | Copper Alloy | Contact Form | - |
| Contact Finish Thickness | 15.0µin (0.38µm) | Contact Finish | Gold |
| Connector Type | Plug, Male Pins | Connector Style | D-Type, Micro-D |
| Color | - | Backset Spacing | - |
