HCTR-684
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HCTR-684 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HCTR-684 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HCTR-684 |
|---|---|
| Manufacturer | API Delevan |
| Description | FIXED IND 29UH 6.57A 25 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $1.889 | $1.731 | $1.133 | |||
| 500 pcs | 1000 pcs | 2500 pcs | |||
| $1.007 | $0.944 | $0.913 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HCTR-684 | Manufacturer | API Delevan |
|---|---|---|---|
| Description | FIXED IND 29UH 6.57A 25 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 34313 pcs | Data sheet | HCT(R) Series |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | ±25% | Supplier Device Package | - |
| Size / Dimension | 0.945" L x 0.940" W (24.00mm x 23.88mm) | Shielding | Shielded |
| Series | HCTR | Ratings | - |
| Q @ Freq | 30 @ 100kHz | Packaging | Bulk |
| Package / Case | Nonstandard | Other Names | DN4806 HCTR-684 BULK 50 HCTR684 |
| Operating Temperature | -30°C ~ 130°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron Powder |
| Manufacturer Standard Lead Time | 17 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 29µH |
| Height - Seated (Max) | 0.400" (10.16mm) | Frequency - Self Resonant | 16MHz |
| Detailed Description | 29µH Shielded Toroidal Inductor 6.57A 25 mOhm Max Nonstandard | DC Resistance (DCR) | 25 mOhm Max |
| Current Rating | 6.57A | Current - Saturation | - |
