76889440047
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 76889440047 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 76889440047 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 76889440047 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | INDUCTOR ARRAY 2 COIL 4.7UH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.487 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 76889440047 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | INDUCTOR ARRAY 2 COIL 4.7UH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 68160 pcs | Data sheet | 76889440047 Drawing |
| Category | Inductors, Coils, Chokes | Tolerance | ±20% |
| Size / Dimension | 0.315" L x 0.315" W (8.00mm x 8.00mm) | Shielding | Shielded |
| Series | WE-TDC HV | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-11696-2 |
| Operating Temperature | -40°C ~ 125°C | Number of Coils | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance - Connected In Parallel | 4.7µH | Height | 0.161" (4.10mm) |
| Detailed Description | Shielded 2 Coil Inductor Array Inductance - Connected in Series 4.7µH Inductance - Connected in Parallel 110 mOhm DC Resistance (DCR) - Parallel 2.45A Nonstandard | DC Resistance (DCR) - Series | - |
| DC Resistance (DCR) - Parallel | 110 mOhm | Current Saturation - Parallel | 4.7A |
| Current Rating - Parallel | 2.45A |
