76889430056
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 76889430056 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 76889430056 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 76889430056 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | INDUCTOR ARRAY 2 COIL 5.6UH SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2000 pcs | ||||
|---|---|---|---|---|---|
| $0.486 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 76889430056 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | INDUCTOR ARRAY 2 COIL 5.6UH SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 75516 pcs | Data sheet | 76889430056 Drawing |
| Category | Inductors, Coils, Chokes | Tolerance | ±20% |
| Size / Dimension | 0.315" L x 0.315" W (8.00mm x 8.00mm) | Shielding | Shielded |
| Series | WE-TDC HV | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-11692-2 |
| Operating Temperature | -40°C ~ 125°C | Number of Coils | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance - Connected In Parallel | 5.6µH | Height | 0.083" (2.10mm) |
| Detailed Description | Shielded 2 Coil Inductor Array Inductance - Connected in Series 5.6µH Inductance - Connected in Parallel 234 mOhm DC Resistance (DCR) - Parallel 1.4A Nonstandard | DC Resistance (DCR) - Series | - |
| DC Resistance (DCR) - Parallel | 234 mOhm | Current Saturation - Parallel | 2A |
| Current Rating - Parallel | 1.4A |
