7687709681
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7687709681 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7687709681 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7687709681 |
|---|---|
| Manufacturer | Wurth Electronics |
| Description | FIXED IND 680UH 800MA 1.15 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 250 pcs | ||||
|---|---|---|---|---|---|
| $0.935 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7687709681 | Manufacturer | Wurth Electronics |
|---|---|---|---|
| Description | FIXED IND 680UH 800MA 1.15 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 39122 pcs | Data sheet | 7687709681 Drawing |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.472" L x 0.472" W (12.00mm x 12.00mm) | Shielding | Shielded |
| Series | WE-PD HV | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 732-4547-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 680µH |
| Height - Seated (Max) | 0.413" (10.50mm) | Frequency - Self Resonant | 1.5MHz |
| Detailed Description | 680µH Shielded Wirewound Inductor 800mA 1.15 Ohm Max Nonstandard | DC Resistance (DCR) | 1.15 Ohm Max |
| Current Rating | 800mA | Current - Saturation | 1.2A |
