Home > Products > Sensors, Transducers > Strain Gauges > MMF003247

MMF003247

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MMF003247 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MMF003247
Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350OHM LINEAR 1=5PC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	25 pcs	50 pcs	100 pcs
~~In Stock~~ 1346 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs
	$31.325	$29.759	$27.409
	$24.277	$23.494	$22.711

Product parameter
Data sheet

Product parameter

Part Number	MMF003247	Manufacturer	Vishay Precision Group
Description	STRAIN GAUGE 350OHM LINEAR 1=5PC	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1346 pcs	Data sheet	Standard Weldable Patterns Guide 250UW
Category	Sensors, Transducers	Width - Overall Pattern	0.180" (4.57mm)
Width - Overall	0.27" (6.9mm)	Width - Active	0.180" (4.57mm)
Strain Range	±5%	Series	CEA
Resistance Tolerance	±0.3%	Resistance	350 Ohms
Pattern Type	Linear	Other Names	1033-1013 CEA-06-250UW-350 CEA06250UW350 F003247
Operating Temperature	-100 ~ 350°F (-75 ~ 175°C)	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Length - Overall Pattern	0.450" (11.43mm)
Length - Overall	0.55" (14.0mm)	Length - Active	0.250" (6.35mm)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Detailed Description	Linear Strain Gauge ±5% 0.250" (6.35mm) 0.180" (4.57mm)
