MMF003224
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MMF003224 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MMF003224 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MMF003224 |
|---|---|
| Manufacturer | Vishay Precision Group |
| Description | STRAIN GAUGE 350 OHM SHEAR 1=5PC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $130.134 | $122.00 | $117.933 | $113.866 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MMF003224 | Manufacturer | Vishay Precision Group |
|---|---|---|---|
| Description | STRAIN GAUGE 350 OHM SHEAR 1=5PC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 347 pcs | Data sheet | Standard Weldable Patterns Guide250US |
| Category | Sensors, Transducers | Width - Overall Pattern | 0.700" (17.78mm) |
| Width - Overall | 0.80" (20.3mm) | Width - Active | 0.120" (3.05mm) per section |
| Strain Range | ±5% | Series | CEA |
| Resistance Tolerance | ±0.4% | Resistance | 350 Ohms |
| Pattern Type | Shear/Torque | Other Names | 1033-1011 CEA-06-250US-350 CEA06250US350 F003224 |
| Operating Temperature | -100 ~ 350°F (-75 ~ 175°C) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 12 Weeks | Length - Overall Pattern | 0.820" (20.83mm) |
| Length - Overall | 0.96" (24.4mm) | Length - Active | 0.250" (6.35mm) per section |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | Shear/Torque Strain Gauge ±5% 0.250" (6.35mm) per section 0.120" (3.05mm) per section |
