Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > PI3523-00-EVAL1

PI3523-00-EVAL1

PI3523-00-EVAL1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PI3523-00-EVAL1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PI3523-00-EVAL1
Manufacturer	Vicor
Description	EVALUATION BOARD FOR PI3523-00-L
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 404 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$73.753

Product parameter
Data sheet

Product parameter

Part Number	PI3523-00-EVAL1	Manufacturer	Vicor
Description	EVALUATION BOARD FOR PI3523-00-L	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	404 pcs	Data sheet	PI352x-0x-Eval1 User Guide PI352x-00 Series Datasheet
Category	Development Boards, Kits, Programmers	Voltage - Output	3.3V
Voltage - Input	2.2 V ~ 4 V	Utilized IC / Part	PI3523-00
Supplied Contents	Board(s)	Series	*
Regulator Topology	Buck	Outputs and Type	1, Non-Isolated
Other Names	1102-5734	Manufacturer Standard Lead Time	16 Weeks
Main Purpose	DC/DC, Step Down	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Detailed Description	PI3523-00 * DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board	Current - Output	22A
Board Type	Fully Populated
