SP-42
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SP-42 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SP-42 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SP-42 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | TRANSER 150 CT/ 12 OHM AUDIO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.956 | $4.398 | $4.06 | $3.924 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.816 | $3.762 | $3.721 | $3.653 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SP-42 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | TRANSER 150 CT/ 12 OHM AUDIO | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9339 pcs | Data sheet | SP-42 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1000VRMS @ 1 Second | Turns Ratio - Primary:Secondary | 3.54:1 |
| Transformer Type | Audio Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.410" L x 0.310" W (10.41mm x 7.87mm) | Series | Red-Spec |
| Return Loss | - | Power Level | 50mW |
| Packaging | Bulk | Other Names | 10636 237-1145 SP42 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 12 |
| Impedance - Primary (Ohms) | 150CT | Height - Seated (Max) | 0.465" (11.80mm) |
| Frequency Response | ±2dB | Frequency Range | 300Hz ~ 100kHz |
| DC Resistance (DCR) - Secondary | 2.7 Ohm | DC Resistance (DCR) - Primary | 18 Ohm |
| Approvals | - |
