SP-4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SP-4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SP-4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SP-4 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | TRANSF 200K CT/1K CT AUDIO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $7.35 | $5.60 | $5.162 | $4.987 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $4.90 | $4.725 | $4.55 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | SP-4 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | TRANSF 200K CT/1K CT AUDIO | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6958 pcs | Data sheet | SP-4 |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1000VRMS @ 1 Second | Turns Ratio - Primary:Secondary | 14.1:1 |
| Transformer Type | Audio Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.410" L x 0.310" W (10.41mm x 7.87mm) | Series | Red-Spec |
| Return Loss | - | Power Level | 10mW |
| Packaging | Bulk | Other Names | 237-1137 SP4 |
| Operating Temperature | - | Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 1kCT |
| Impedance - Primary (Ohms) | 200kCT | Height - Seated (Max) | 0.465" (11.80mm) |
| Frequency Response | ±2dB | Frequency Range | 300Hz ~ 100kHz |
| DC Resistance (DCR) - Secondary | 100 Ohm | DC Resistance (DCR) - Primary | 5.3 kOhm |
| Approvals | - |
