FS24-100
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FS24-100 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FS24-100 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FS24-100 |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | XFRMR LAMINATED 2.4VA THRU HOLE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.193 | $2.482 | $2.415 | $2.08 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.986 | $1.945 | $1.912 | $1.878 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | FS24-100 | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | XFRMR LAMINATED 2.4VA THRU HOLE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19430 pcs | Data sheet | FS24-100 |
| Category | Transformers | Weight | 0.25 lb (113.4g) |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 2500Vrms | Type | Laminated Core |
| Termination Style | PC Pin | Size / Dimension | 34.93mm L x 28.58mm W |
| Series | Split Pack™ | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 2.4 VA |
| Other Names | 10449 237-1035 FS24100 |
Mounting Type | Through Hole |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 30.15mm | Current - Output (Max) | Parallel 200mA, Series 100mA |
| Center Tap | No |
