F-109U
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-109U with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-109U with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-109U |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | POWER XFMR CHASSIS MOUNT W/LUGS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $14.992 | $14.491 | $13.491 | $12.492 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | F-109U | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | POWER XFMR CHASSIS MOUNT W/LUGS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2934 pcs | Data sheet | F-109U Datasheet |
| Category | Transformers | Weight | 8 lbs (3.6kg) |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder Lug | Size / Dimension | 87.30mm L x 90.47mm W |
| Series | Control Transformers | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 192 VA |
| Other Names | 237-1899 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 106.35mm |
| Current - Output (Max) | Parallel 16A, Series 8A | Center Tap | No |
