F-105Z
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy F-105Z with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy F-105Z with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | F-105Z |
|---|---|
| Manufacturer | Triad Magnetics |
| Description | POWER XFMR CHASSIS MOUNT W/LUGS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.952 | $4.535 | $4.181 | $4.039 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.968 | $3.826 | $3.685 | $3.543 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | F-105Z | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | POWER XFMR CHASSIS MOUNT W/LUGS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9898 pcs | Data sheet | F-105Z Datasheet |
| Category | Transformers | Weight | 1 lb (453.59g) |
| Voltage - Secondary (Full Load) | Parallel 6V, Series 12V | Voltage - Primary | 115V, 230V |
| Voltage - Isolation | 1500Vrms | Type | Laminated Core |
| Termination Style | Solder Lug | Size / Dimension | 73.02mm L x 44.45mm W |
| Series | Control Transformers | Secondary Winding(s) | Dual |
| Primary Winding(s) | Dual | Power - Max | 12 VA |
| Other Names | 237-1895 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 60.32mm |
| Current - Output (Max) | Parallel 2A, Series 1A | Center Tap | No |
