TLP371F
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TLP371F with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TLP371F with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TLP371F |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | OPTOISO 5KV DARL W/BASE 6DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | TLP371F | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | OPTOISO 5KV DARL W/BASE 6DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3983 pcs | Data sheet | TLP731(32) |
| Category | Isolators | Voltage - Output (Max) | 300V |
| Voltage - Isolation | 5000Vrms | Voltage - Forward (Vf) (Typ) | 1.15V |
| Vce Saturation (Max) | 1.2V | Turn On / Turn Off Time (Typ) | 50µs, 15µs |
| Supplier Device Package | 6-DIP | Series | - |
| Rise / Fall Time (Typ) | 40µs, 15µs | Packaging | Tube |
| Package / Case | 6-DIP (0.300", 7.62mm) | Output Type | Darlington with Base |
| Other Names | Q11650343 Q12024057 TLP371 (F) TLP371(F) |
Operating Temperature | -55°C ~ 100°C |
| Number of Channels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | DC | Detailed Description | Optoisolator Darlington with Base Output 5000Vrms 1 Channel 6-DIP |
| Current Transfer Ratio (Min) | 1000% @ 1mA | Current Transfer Ratio (Max) | - |
| Current - Output / Channel | 150mA | Current - DC Forward (If) (Max) | 60mA |
