SSM4K27CTTPL3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SSM4K27CTTPL3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SSM4K27CTTPL3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SSM4K27CTTPL3 |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 20V .5A CST4 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SSM4K27CTTPL3 | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | MOSFET N-CH 20V .5A CST4 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4188 pcs | Data sheet | SSM4K27CTMosfets Prod Guide |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 1.1V @ 1mA |
| Vgs (Max) | ±12V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | CST4 (1.2x0.8) | Series | U-MOSIII |
| Rds On (Max) @ Id, Vgs | 205 mOhm @ 250mA, 4V | Power Dissipation (Max) | 400mW (Ta) |
| Packaging | Original-Reel® | Package / Case | 4-SMD, No Lead |
| Other Names | SSM4K27CT(TPL3)DKR SSM4K27CT(TPL3)DKR-ND SSM4K27CTTPL3DKR |
Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 174pF @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4V | Drain to Source Voltage (Vdss) | 20V |
| Detailed Description | N-Channel 20V 500mA (Ta) 400mW (Ta) Surface Mount CST4 (1.2x0.8) | Current - Continuous Drain (Id) @ 25°C | 500mA (Ta) |
