TTC-108N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TTC-108N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TTC-108N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TTC-108N |
|---|---|
| Manufacturer | Tamura |
| Description | TRANSFORMER 600CT:600CT 0MADC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.655 | $2.018 | $1.965 | $1.806 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.699 | $1.646 | $1.593 | $1.54 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | TTC-108N | Manufacturer | Tamura |
|---|---|---|---|
| Description | TRANSFORMER 600CT:600CT 0MADC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25685 pcs | Data sheet | TTC-108N |
| Category | Transformers | Weight | - |
| Voltage - Isolation | 1500VRMS @ 1 Minute | Turns Ratio - Primary:Secondary | 1:1 |
| Transformer Type | Data/Voice Coupling | Termination Style | PC Pin |
| Size / Dimension | 0.815" L x 0.650" W (20.70mm x 16.50mm) | Series | TTC |
| Return Loss | - | Power Level | -45dB ~ 7dB |
| Packaging | Bulk | Other Names | MT7385 Q1248008 Q1429352 TTC-108N-ND |
| Operating Temperature | - | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.4dB Max @ 1kHz |
| Impedance - Secondary (Ohms) | 600CT | Impedance - Primary (Ohms) | 600CT |
| Height - Seated (Max) | 0.736" (18.70mm) | Frequency Response | ±0.5dB |
| Frequency Range | 300Hz ~ 3.5kHz | DC Resistance (DCR) - Secondary | 56 Ohm |
| DC Resistance (DCR) - Primary | 44 Ohm | Approvals | CSA-C22.2 No. 66-M1988, UL1459 |
