AS-104
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AS-104 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AS-104 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AS-104 |
|---|---|
| Manufacturer | Talema |
| Description | CURR SENSE XFMR 1:500 15A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2500 pcs | ||||
|---|---|---|---|---|---|
| $0.516 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AS-104 | Manufacturer | Talema |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:500 15A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76113 pcs | Data sheet | AS Series |
| Category | Transformers | Weight | - |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | 1:500 |
| Termination Style | PC Pin | Size / Dimension | 0.677" L x 0.375" W (17.20mm x 9.53mm) |
| Series | AS | Ratings | - |
| Packaging | Tray | Other Names | 1295-1124 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 700mH | Height - Seated (Max) | 0.803" (20.40mm) |
| Frequency Range | 20kHz ~ 200kHz | Energy Time (E.T.) | 1500V µS |
| Detailed Description | 15A 1:500 Current Sense Transformer 20kHz ~ 200kHz 25 Ohm Secondary 700mH Through Hole | DC Resistance (DCR) | 25 Ohm Secondary |
| Current Ratio | - | Current Rating | 15A |
