AS-114
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AS-114 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AS-114 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AS-114 |
|---|---|
| Manufacturer | AlfaMag Electronics (AMGIS) |
| Description | CURR SENSE XFMR 1:500CT 15A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | ||||
|---|---|---|---|---|---|
| $0.996 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AS-114 | Manufacturer | AlfaMag Electronics (AMGIS) |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:500CT 15A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 32919 pcs | Data sheet | AS Series |
| Category | Transformers | Weight | - |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | 1:500CT |
| Termination Style | PC Pin | Size / Dimension | 0.677" L x 0.375" W (17.20mm x 9.53mm) |
| Series | AS | Ratings | - |
| Packaging | Tray | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 700mH |
| Height - Seated (Max) | 0.803" (20.40mm) | Frequency Range | 20kHz ~ 200kHz |
| Energy Time (E.T.) | 1500V µS | Detailed Description | 1:500CT Current Sense Transformer 20kHz ~ 200kHz 12.5 Ohm Max 700mH Through Hole |
| DC Resistance (DCR) | 12.5 Ohm Max | Current Ratio | - |
