Home > Products > Power Supplies - Board Mount > DC DC Converters > PXE2048WS12

PXE2048WS12

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PXE2048WS12 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PXE2048WS12
Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER 12V 20W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1467 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs
Reference Price (In US Dollars)	$24.348	$22.894

Product parameter
Data sheet

Product parameter

Part Number	PXE2048WS12	Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER 12V 20W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1467 pcs	Data sheet	PXE20-xx(W)Sxx Datasheet PXE Sgl Instr Manual PXE Series Overview
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-	Voltage - Output 1	12V
Voltage - Isolation	1.6kV	Voltage - Input (Min)	18V
Voltage - Input (Max)	75V	Type	Isolated Module
Size / Dimension	2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 8.6mm)	Series	PXE
Power (Watts)	20W	Packaging	Bulk
Package / Case	8-DIP Module, 6 Leads	Other Names	285-1534 PXE20-48WS12
Operating Temperature	-40°C ~ 100°C	Number of Outputs	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	Not Applicable
Manufacturer Standard Lead Time	16 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Remote On/Off	Efficiency	81%
Detailed Description	Isolated Module DC DC Converter 1 Output 12V 1.67A 18V - 75V Input	Current - Output (Max)	1.67A
Applications	ITE (Commercial)
