Home > Products > Power Supplies - Board Mount > DC DC Converters > PXE2048WD15

PXE2048WD15

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PXE2048WD15 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PXE2048WD15
Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER +/-15V 20W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1091 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$27.783

Product parameter
Data sheet

Product parameter

Part Number	PXE2048WD15	Manufacturer	TDK-Lambda Americas, Inc.
Description	DC DC CONVERTER +/-15V 20W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1091 pcs	Data sheet	PXE20-xx(W)Sxx Datasheet PXE Series Overview PXE Dual Instr Manual
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-15V	Voltage - Output 1	15V
Voltage - Isolation	1.6kV	Voltage - Input (Min)	18V
Voltage - Input (Max)	75V	Type	Isolated Module
Size / Dimension	2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 8.6mm)	Series	PXE
Power (Watts)	20W	Packaging	Bulk
Package / Case	8-DIP Module, 7 Leads	Other Names	285-1532 PXE20-48WD15
Operating Temperature	-40°C ~ 100°C	Number of Outputs	2
Mounting Type	Through Hole	Manufacturer Standard Lead Time	16 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	Remote On/Off
Efficiency	84%	Detailed Description	Isolated Module DC DC Converter 2 Output 15V -15V 666mA, 666mA 18V - 75V Input
Current - Output (Max)	666mA, 666mA	Applications	ITE (Commercial)
