Home > Products > Inductors, Coils, Chokes > Wireless Charging Coils > WT252512-8F2-SM

WT252512-8F2-SM

WT252512-8F2-SM

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy WT252512-8F2-SM with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	WT252512-8F2-SM
Manufacturer	TDK Corporation
Description	TX 1 COIL 1 LAYER 2.76UH
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 20316 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	336 pcs	672 pcs	1008 pcs
Reference Price (In US Dollars)	$2.827	$2.568	$1.644	$1.592	$1.49

Product parameter
Data sheet

Product parameter

Part Number	WT252512-8F2-SM	Manufacturer	TDK Corporation
Description	TX 1 COIL 1 LAYER 2.76UH	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	20316 pcs	Data sheet	WT252512-8F2-SM Datasheet~WT252512-8F2-SM Spec
Category	Inductors, Coils, Chokes	Type	1 Coil, 1 Layer
Tolerance	±5%	Size / Dimension	0.984" Dia x 0.007" H (25.00mm x 2.05mm)
Series	WT	Q @ Freq	-
Other Names	445-174603	Operating Temperature	-
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Inductance	2.76µH	Function	Transmitter
Frequency - Self Resonant	-	Detailed Description	1 Coil, 1 Layer 2.76µH Wireless Charging Coil Transmitter 70 mOhm
DC Resistance (DCR)	70 mOhm	Current Rating	-
Current - Saturation	-
