WT1005690-12K2-A6-G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy WT1005690-12K2-A6-G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy WT1005690-12K2-A6-G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | WT1005690-12K2-A6-G |
|---|---|
| Manufacturer | TDK Corporation |
| Description | TX 3 COIL 1 LAYER 11.5 - 12.5UH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 36 pcs | 108 pcs | 504 pcs | 1008 pcs |
|---|---|---|---|---|---|
| $4.005 | $3.503 | $3.003 | $2.802 | $2.662 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | WT1005690-12K2-A6-G | Manufacturer | TDK Corporation |
|---|---|---|---|
| Description | TX 3 COIL 1 LAYER 11.5 - 12.5UH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12524 pcs | Data sheet | WT-1005690-12K2-A6-G Datasheet |
| Category | Inductors, Coils, Chokes | Type | 3 Coil, 1 Layer |
| Tolerance | - | Size / Dimension | 3.94" L x 2.20" W x 0.19" H (100.0mm x 56mm x 4.8mm) |
| Series | WT | Q @ Freq | - |
| Other Names | 445-16096 | Operating Temperature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 11.5 ~ 12.5µH |
| Function | Transmitter | Frequency - Self Resonant | - |
| Detailed Description | 3 Coil, 1 Layer 11.5 ~ 12.5µH Wireless Charging Coil Transmitter 80 mOhm | DC Resistance (DCR) | 80 mOhm |
| Current Rating | - | Current - Saturation | - |
