SPM6550T-R68M-HZ
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SPM6550T-R68M-HZ with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SPM6550T-R68M-HZ with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SPM6550T-R68M-HZ |
|---|---|
| Manufacturer | TDK Corporation |
| Description | FIX IND 680NH 25.2A 3.74MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | 3000 pcs | 5000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.347 | $0.336 | $0.324 | $0.313 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SPM6550T-R68M-HZ | Manufacturer | TDK Corporation |
|---|---|---|---|
| Description | FIX IND 680NH 25.2A 3.74MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 60912 pcs | Data sheet | SPM6550T-HZ Type, Automotive |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±20% | Supplier Device Package | - |
| Size / Dimension | 0.280" L x 0.256" W (7.10mm x 6.50mm) | Shielding | Shielded |
| Series | SPM-HZ | Ratings | AEC-Q200 |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard | Other Names | 445-180115-2 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Metal |
| Manufacturer Standard Lead Time | 25 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 100kHz | Inductance | 680nH |
| Height - Seated (Max) | 0.197" (5.00mm) | Frequency - Self Resonant | - |
| Features | - | Detailed Description | 680nH Shielded Wirewound Inductor 25.2A 3.74 mOhm Max Nonstandard |
| DC Resistance (DCR) | 3.74 mOhm Max | Current Rating | 25.2A |
| Current - Saturation | 12.4A |
