ACM4520V-142-2P-T00
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ACM4520V-142-2P-T00 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ACM4520V-142-2P-T00 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ACM4520V-142-2P-T00 |
|---|---|
| Manufacturer | TDK Corporation |
| Description | CMC 1A 2LN 1.4 KOHM SMD AEC-Q200 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 800 pcs | 1600 pcs | 4000 pcs | 5600 pcs | |
|---|---|---|---|---|---|
| $0.244 | $0.23 | $0.223 | $0.216 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ACM4520V-142-2P-T00 | Manufacturer | TDK Corporation |
|---|---|---|---|
| Description | CMC 1A 2LN 1.4 KOHM SMD AEC-Q200 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 94300 pcs | Data sheet | ACM4520V Series, Automotive |
| Category | Filters | Voltage Rating - DC | 50V |
| Voltage Rating - AC | - | Size / Dimension | 0.185" L x 0.177" W (4.70mm x 4.50mm) |
| Series | ACM-V | Ratings | AEC-Q200 |
| Packaging | Tape & Reel (TR) | Package / Case | Horizontal, 4 PC Pad |
| Other Names | 445-15674-2 | Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 25 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Impedance @ Frequency | 1.4 kOhms @ 100MHz |
| Height (Max) | 0.079" (2.00mm) | Filter Type | Power Line |
| Features | - | Detailed Description | 2 Line Common Mode Choke Surface Mount 1.4 kOhms @ 100MHz 1A DCR 80 mOhm |
| DC Resistance (DCR) (Max) | 80 mOhm | Current Rating (Max) | 1A |
| Approvals | - |
