PC725V0NIZX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PC725V0NIZX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PC725V0NIZX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PC725V0NIZX |
|---|---|
| Manufacturer | Sharp Microelectronics |
| Description | OPTOISO 5KV DARL W/BASE 6SMD |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | PC725V0NIZX | Manufacturer | Sharp Microelectronics |
|---|---|---|---|
| Description | OPTOISO 5KV DARL W/BASE 6SMD | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5109 pcs | Data sheet | PC725V0NSZX Series |
| Category | Isolators | Voltage - Output (Max) | 300V |
| Voltage - Isolation | 5000Vrms | Voltage - Forward (Vf) (Typ) | 1.2V |
| Vce Saturation (Max) | 1.2V | Turn On / Turn Off Time (Typ) | - |
| Supplier Device Package | 6-SMD | Series | - |
| Rise / Fall Time (Typ) | 100µs, 20µs | Packaging | Tube |
| Package / Case | 6-SMD, Gull Wing | Output Type | Darlington with Base |
| Other Names | 425-1427-5 | Operating Temperature | -25°C ~ 100°C |
| Number of Channels | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Input Type | DC | Detailed Description | Optoisolator Darlington with Base Output 5000Vrms 1 Channel 6-SMD |
| Current Transfer Ratio (Min) | 1000% @ 1mA | Current Transfer Ratio (Max) | 15000% @ 1mA |
| Current - Output / Channel | 150mA | Current - DC Forward (If) (Max) | 50mA |
