RN222-3-02
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RN222-3-02 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RN222-3-02 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RN222-3-02 |
|---|---|
| Manufacturer | Schaffner EMC, Inc. |
| Description | CMC 4.5MH 3A 2LN TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | RN222-3-02 | Manufacturer | Schaffner EMC, Inc. |
|---|---|---|---|
| Description | CMC 4.5MH 3A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5579 pcs | Data sheet | RN Series Datasheet |
| Category | Filters | Voltage Rating - DC | - |
| Voltage Rating - AC | 250V | Size / Dimension | 1.220" L x 0.709" W (31.00mm x 18.00mm) |
| Series | RN | Ratings | - |
| Packaging | Tray | Package / Case | Vertical, 4 PC Pin |
| Other Names | 290-161 800436 817-2047 RN222-3-02-ND |
Operating Temperature | -40°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance @ Frequency | 4.5mH @ 1kHz | Height (Max) | 1.165" (29.60mm) |
| Filter Type | Power Line | Features | - |
| Detailed Description | 4.5mH @ 1kHz 2 Line Common Mode Choke Through Hole 3A (Typ) DCR 82.6 mOhm (Typ) | DC Resistance (DCR) (Max) | 82.6 mOhm (Typ) |
| Current Rating (Max) | 3A (Typ) | Approvals | UR, VDE |
