EVL6566B-40WSTB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EVL6566B-40WSTB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy EVL6566B-40WSTB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | EVL6566B-40WSTB |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | BOARD EVAL FOR L6566B |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $14.14 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | EVL6566B-40WSTB | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | BOARD EVAL FOR L6566B | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2590 pcs | Data sheet | L6566BHL6566BEVL6566B-40WSTB Data BriefEVL6566B-40WSTB Appl Note |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 5V, 12V, 1.8V, 3.3V |
| Voltage - Input | 90 ~ 264 VAC | Utilized IC / Part | L6566B |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Flyback | Power - Output | 40W |
| Outputs and Type | 4, Isolated | Other Names | 497-6450 EVL6566B40WSTB |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | AC/DC, Primary Side |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Switching | 62kHz |
| Detailed Description | L6566B - AC/DC, Primary Side 4, Isolated Outputs Evaluation Board | Current - Output | 2.4A, 1.9A, 1.73A, 500mA |
| Board Type | Fully Populated |
