ESDZV5-1BF4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ESDZV5-1BF4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ESDZV5-1BF4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ESDZV5-1BF4 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | TVS DIODE 5.5V 10V 0201 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.069 | $0.062 | $0.034 | $0.021 | $0.014 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ESDZV5-1BF4 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | TVS DIODE 5.5V 10V 0201 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1563912 pcs | Data sheet | ESDZV5-1BF4 Datasheet |
| Category | Circuit Protection | Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Clamping (Max) @ Ipp | 10V | Voltage - Breakdown (Min) | - |
| Type | Zener | Supplier Device Package | 0201 |
| Series | ESDZ | Power Line Protection | No |
| Power - Peak Pulse | 70W | Packaging | Cut Tape (CT) |
| Package / Case | 0201 (0603 Metric) | Other Names | 497-17318-1 |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Manufacturer Standard Lead Time | 15 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Current - Peak Pulse (10/1000µs) | 7A (8/20µs) | Capacitance @ Frequency | 6pF @ 1MHz |
| Bidirectional Channels | 1 | Applications | General Purpose |
