ESDZL5-1F4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ESDZL5-1F4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ESDZL5-1F4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ESDZL5-1F4 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | TVS DIODE 5.5V 10V 0201 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 15000 pcs | 30000 pcs | 75000 pcs | 105000 pcs | |
|---|---|---|---|---|---|
| $0.009 | $0.008 | $0.007 | $0.006 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ESDZL5-1F4 | Manufacturer | STMicroelectronics |
|---|---|---|---|
| Description | TVS DIODE 5.5V 10V 0201 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3792946 pcs | Data sheet | Power Mgmt Guide BrochureESDZL5-1F4 |
| Category | Circuit Protection | Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Clamping (Max) @ Ipp | 10V | Voltage - Breakdown (Min) | - |
| Unidirectional Channels | 1 | Type | Zener |
| Supplier Device Package | 0201 | Series | ESDZ |
| Power Line Protection | No | Power - Peak Pulse | 60W |
| Packaging | Tape & Reel (TR) | Package / Case | 0201 (0603 Metric) |
| Other Names | 497-17544-2 | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Current - Peak Pulse (10/1000µs) | 7A (8/20µs) |
| Capacitance @ Frequency | 7.5pF @ 1MHz | Applications | General Purpose |
