X-1584NL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy X-1584NL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy X-1584NL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | X-1584NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | TRANSFORMER SINGLE 1553 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 55 pcs | 110 pcs |
|---|---|---|---|---|---|
| $9.619 | $8.488 | $8.205 | $7.356 | $7.073 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | X-1584NL | Manufacturer | Pulse Electronics Corporation |
|---|---|---|---|
| Description | TRANSFORMER SINGLE 1553 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5274 pcs | Data sheet | Military/Aerospace Product GuideX-1584,1596 Series Datasheet |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 1CT:1.79CT | Transformer Type | Interface, MIL-STD-1553 |
| Size / Dimension | 0.350" L x 0.500" W (8.89mm x 12.70mm) | Series | - |
| Other Names | 1902-1057-5 | Operating Temperature | -55°C ~ 130°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | - | Height - Seated (Max) | 0.172" (4.37mm) |
| Energy Time (E.T.) | - |
